| Manufacturer | Kartell UK Ltd |
|---|---|
| Manufacturer Warranty | 5 Years (T&C’s Apply) |
| Orientation | Vertical Orientation |
| Panel Type | Double Panel Radiator |
| Colour | White |
| Height | 1800 mm |
| Heat Output Watts | 1,367W — 2,461W |
| Heat Output BTU | 4,664 — 8,397 |
| Radiator Pipe Centres (mm) (Plus Valves) | 300mm / 420mm / 540mm (width dependent) |
| Radiator Wall To Pipe Centres (mm) | 51mm |
| Radiator Colour | White |
| Model | Aspen White Vertical Double |
| Brand | K-Rad Designer Range |
| Fuel Type | Central Heating |
| Width (mm) | 300mm / 420mm / 540mm |
| Product Type | Double Panel Radiator |
| Depth (mm) | 79 |
| Height (mm) | 1800 |
Home > Radiators > Designer Radiators > Vertical Radiators > Kartell K-Rad Aspen 1800mm Double White Vertical Radiator
A full-height double panel designer vertical radiator in gloss white. Available in three widths delivering between 4,664 and 8,397 BTU. Select your width from the dropdown above. 5 year Kartell UK guarantee. All fixings included. Free delivery on orders over £500.
The double panel delivers nearly double the heat of the single panel version from the same wall width. Three widths available to suit any room. Use the BTU Calculator tab to confirm.
Standing at 1800mm tall, the Aspen makes a bold design statement while maximising heat output. The oval tube design provides a premium look over standard flat panel alternatives.
The gloss white finish suits all interior styles from traditional to contemporary. Matches standard UK plumbing fittings and radiator valves for a seamless installation.
Slightly deeper than the single panel at 55mm, but the additional heat output is substantial. Ideal where wall space is available and maximum warmth is the priority.
Registered directly with Kartell UK. All wall brackets, fixing screws, wall plugs, air vent and blanking plug included as standard. Pressure tested to 7.8 bar.
Need a slimmer profile? The Aspen 1800mm Single White delivers from 2,392 to 4,309 BTU at just 55mm deep.
| Width | SKU | BTU (ΔT60) | Watts | Pipe Centres | Room Guide |
|---|---|---|---|---|---|
| 300mm | ASP18-31VDW | 4,664 | 1,367W | 300mm | Small rooms, narrow alcoves |
| 420mm ★ Most Popular | ASP18-43VDW | 6,531 | 1,914W | 420mm | Living rooms, hallways, bedrooms |
| 540mm | ASP18-55VDW | 8,397 | 2,461W | 540mm | Large rooms, open-plan spaces |
| Specification | Detail |
|---|---|
| Height | 1800mm |
| Depth | 79mm |
| Colour / Finish | Gloss White |
| Material | Mild Steel |
| Style | Double Panel — Oval Tube Designer |
| Orientation | Vertical |
| Wall to Pipe Centres | 51mm (all widths) |
| Valve Connection | 1/2 inch BSP |
| Max Working Pressure | 7.8 bar |
| Compatible Systems | Gas, oil, electric, heat pump — sealed and open vented |
| Fixings Supplied | Yes — all fixings included |
| Manufacturer Guarantee | 5 years — Kartell UK |
| Valves | Not included — sold separately (see Valves tab) |
Understanding Delta T60: All BTU figures are quoted at Delta T60 — the European standard assuming mean water temperature 60°C above room temperature. Most modern combi boilers operate at or near this standard.
Watch our step-by-step installation guide below. Professional installation by a Gas Safe registered engineer is strongly recommended for all connections to gas central heating systems.
| Height | 1800mm (all widths) |
| Depth / Wall Projection | 79mm (all widths) |
| Pipe Centres | Matches width: 300mm / 420mm / 540mm |
| Wall to Pipe Centres | 51mm (all widths) |
| Valve Connection | 1/2 inch BSP — angled, straight, or corner valves |
| Max Working Pressure | 7.8 bar |
| Compatible Systems | Sealed and open vented — gas, oil, electric, heat pump |
| Fixings Supplied | Yes — wall brackets, screws, plugs, air vent, blanking plug |
Valves are not included and must be purchased separately. For this gloss white radiator we recommend White TRV valves for a seamless match. Select your pipework type below.
When to use: Pipework rises vertically from the floor to the side connections. The most common UK installation type.
When to use: Pipework rises from the floor and connects directly in a straight vertical line to the bottom tappings.
When to use: Pipework comes horizontally out of the wall to the side connections of the radiator.
Looking for a 1800mm double white vertical radiator? The Kartell K-Rad Aspen 1800mm Double White Vertical Radiator (ASP18-VDW) is available in three widths: 300mm (ASP18-31VDW, 4,664 BTU), 420mm (ASP18-43VDW, 6,531 BTU) and 540mm (ASP18-55VDW, 8,397 BTU). Also found via: 1800mm double white vertical radiator UK, 1800 x 300mm double white vertical designer radiator, 1800 x 420mm double white vertical designer radiator, 1800 x 540mm double white vertical designer radiator, Kartell Aspen 1800 double white, K-Rad Aspen VDW range, tall white double panel vertical radiator UK, 1800mm gloss white double radiator, white double panel designer vertical radiator 1800mm.
