| Manufacturer | Eastbrook Company |
|---|---|
| Manufacturer Warranty | 5 Years (T&C’s Apply) |
| Weight | 16.07 |
| Orientation | Vertical Orientation |
| Panel Type | Double Panel Radiator |
| Colour | White |
| Height | 1800 mm |
| Width | 1040 mm |
| Heat Output Watts | 909 |
| Heat Output BTU | 3100 |
| Radiator Projection (mm) | 96.5 |
| Radiator Colour | Gloss White |
| Model | Addington Aluminium Type 20 |
| Brand | Eastbrook |
| Fuel Type | Central Heating |
| Width (mm) | 366 |
| Product Type | Type 20 |
| Depth (mm) | 96.5 |
| Height (mm) | 1800 |
| Manufacturer | Eastbrook |
| Manufacturer Part No | 86.0408 |
A slim, flat-panel aluminium vertical radiator: 3,100 BTU (909W) at ΔT50 from a 366mm-wide footprint. Aluminium heats up fast and holds little water, so it suits modern boilers and low-temperature heat pump systems. 5 year Eastbrook warranty.
Aluminium transfers heat far faster than steel and the radiator holds much less water, so rooms warm up quicker and less energy is spent heating water that sits in the system.
Eastbrook publishes the low-temperature figure: 1,542 BTU (452W) at ΔT30. That is the number to use when sizing radiators for an air source heat pump.
Puts 3,100 BTU (ΔT50) onto a strip of wall barely wider than a door frame. Ideal for hallways, landings and beside patio doors.
Two flat aluminium panels, no convector fins. Clean flat front and back, with around double the output of the single-panel Type 10 of the same size.
16.07kg net — light for a 1.8m radiator, which makes one-person positioning and plasterboard-friendly fixing easier.
Backed by Eastbrook, one of the UK’s largest radiator suppliers, based in Gloucester.
| Specification | Detail |
|---|---|
| Product Name | Eastbrook Addington Aluminium Vertical Radiator 1800 x 366mm Type 20 Gloss White |
| Manufacturer Code (MPN) | 86.0408 |
| EAN / GTIN | 5056518000600 |
| Brand / Range | Eastbrook / Addington Aluminium |
| Height | 1800mm |
| Width | 366mm |
| Wall Projection | 96.5mm |
| Radiator Body Depth | 63mm |
| Orientation | Vertical |
| Design | Type 20 — double panel, no convector fins |
| Material | Aluminium |
| Colour / Finish | Gloss White |
| Heat Output ΔT50 | 3,100 BTU / 909W |
| Heat Output ΔT30 | 1,542 BTU / 452W |
| Fuel Type | Wet central heating — boiler or heat pump |
| Electric Option | Available fluid-filled with a 600W element — see the electric version |
| Net Weight | 16.07kg |
| Gross (Packed) Weight | 18.59kg |
| Pipe Centres | See the manufacturer technical drawing, or call us to confirm before ordering |
| Manufacturer Warranty | 5 years — Eastbrook |
| Valves | Not included — sold separately (see the Valves tab) |
We recommend installation by a qualified heating engineer. Work on gas boiler systems must be carried out by a Gas Safe registered engineer.
| Wall Projection | 96.5mm |
| Pipe Centres | Check the Eastbrook technical drawing before you order, or call 01282 429061 |
| Compatible Systems | Sealed and open-vented wet central heating — gas, oil and LPG boilers and heat pumps |
| Inhibitor | Aluminium radiators need an aluminium-compatible central heating inhibitor. Check your inhibitor is marked safe for mixed-metal / aluminium systems |
| Fixing | Heavy-duty fixings suited to your wall type. On plasterboard, fix into studs or use rated cavity fixings |
| Instructions | Eastbrook installation instructions are supplied in the box |
Valves are not included. For a gloss white radiator, white valves give the neatest finish. Choose by where your pipes come from.
When to use: pipes come up from the floor into side connections — the most common UK set-up.
When to use: pipes rise from the floor straight into bottom connections.
When to use: pipes come out of the wall horizontally.
