| Manufacturer | Kartell UK Ltd |
|---|---|
| Manufacturer Warranty | 5 Years (T&C’s Apply) |
| Weight | 25.89 |
| Orientation | Horizontal Orientation |
| Panel Type | Double Panel Radiator |
| Colour | White |
| Height | 600 mm |
| Width | 1440 mm |
| Heat Output BTU | 6223 |
| Radiator Pipe Centres (mm) (Plus Valves) | 1140 |
| Radiator Wall To Pipe Centres (mm) | 60 |
| Radiator Colour | White |
| Model | Aspen White Horizontal Double |
| Brand | K-Rad Designer Range |
| Fuel Type | Central Heating |
| Width (mm) | 1140 |
| Depth (mm) | 79 |
| Height (mm) | 600 |
| Manufacturer Part No | ASP60-115DW |
Home > Radiators > Designer Radiators > Horizontal Radiators > KRAD Aspen 600 x 1140mm White Horizontal Double
A high-output horizontal designer radiator delivering 6,223 BTU across a wide 1140mm span. 600mm low-profile height, double panel construction, 79mm depth. Premium white gloss finish. 5 year Kartell UK manufacturer guarantee. All fixings included.
The KRAD Aspen 600 x 1140mm White Horizontal Double Radiator is a purpose-built under-window heating solution designed to span wide living room walls without obstructing the view outside. Measuring just 600mm high, it fits neatly beneath standard double-glazed windows, while its generous 1140mm width delivers a substantial 6,223 BTU (1,824W). The double-panel construction maximises heat output while maintaining a neat 79mm projection from the wall. Finished in crisp white gloss. SKU: ASP60-115DW.
At just 600mm high, this radiator complies with standard building regulations for installations beneath windows, maximising wall space and natural light.
Covers a massive expanse of wall with a single unit, distributing heat evenly across long living rooms, dining spaces, or hallways.
The bright white gloss powder coat is easy to clean, highly durable, and seamlessly matches existing white window frames and internal decor.
The double-panel design provides rapid heat-up times and sustained warmth, easily heating medium to large living spaces as a primary heat source.
Registered directly with Kartell UK, covering all manufacturing defects from the date of purchase for total peace of mind.
Projects just 79mm from the wall, keeping the radiator flush and unobtrusive while still delivering powerful convection and radiation heat.
| Specification | Detail |
|---|---|
| Product Name | KRAD Aspen 600mm X 1140mm White Horizontal Double Designer Radiator |
| SKU / Kartell Code | ASP60-115DW |
| EAN / GTIN | 5055681407506 |
| Height | 600mm |
| Width | 1140mm |
| Depth (Total Wall Distance) | 79mm |
| Orientation | Horizontal |
| Colour / Finish | White (Gloss Powder Coat) |
| Material | Mild Steel |
| Style | Double Panel — Designer |
| BTU Output (Delta T60) | 6,223 BTU |
| Watt Output (Delta T60) | 1,824W |
| Fuel Type | Central heating — gas, oil, or electric |
| Pipe Centres | 1140mm |
| Wall to Pipe Centres | 60mm |
| Valve Connection | 1/2 inch BSP |
| Max Working Pressure | 7.8 bar |
| Fixings Supplied | Yes — all fixings included |
| Manufacturer Guarantee | 5 years — Kartell UK |
| Valves | Not included — sold separately (see Valves tab) |
All outputs quoted at Delta T60 — the European standard assuming mean water temperature 60°C above room temperature.
Watch our step-by-step installation guide below. Professional installation by a Gas Safe registered engineer is strongly recommended for all connections to gas central heating systems.
| Pipe Centres | 1140mm |
| Wall to Pipe Centres | 60mm |
| Wall Projection | 79mm |
| Valve Connection | 1/2 inch BSP — angled or straight valves at either end |
| Max Working Pressure | 7.8 bar |
| Compatible Systems | Sealed and open vented — gas, oil, electric |
| Fixings Supplied | Yes — wall brackets, screws, plugs, air vent, blanking plug |
Valves are not included and must be purchased separately. For this white horizontal radiator, you will typically need a pair of White or Chrome TRV valves (one for each end of the radiator). Select your pipework type below.
When to use: Pipework rises vertically from the floor at either end of the radiator and connects to the bottom tappings. The most common UK installation type for horizontal radiators.
When to use: Pipework comes straight up from the floor directly into the bottom of the radiator at either end.
When to use: Pipework comes horizontally out of the wall at either end and connects to the side of the radiator valves.
Looking for a white horizontal designer radiator close to this size? The KRAD Aspen 600 x 1140mm White Horizontal Double (SKU: ASP60-115DW) is the closest match for: 600 x 1140mm double white horizontal radiator, wide under-window white radiator 6223 BTU, ASP60-115DW, Kartell Aspen 600 1140 double gloss white, long white designer horizontal radiator UK, 79mm projection horizontal radiator 1140mm.
