| Manufacturer | Kartell UK Ltd |
|---|---|
| Manufacturer Warranty | 5 Years (T&C’s Apply) |
| Weight | 17.28 |
| Orientation | Horizontal Orientation |
| Panel Type | Single Panel Radiator |
| Colour | Anthracite |
| Height | 600 mm |
| Width | 1440 mm |
| Heat Output BTU | 4227 |
| Radiator Pipe Centres (mm) (Plus Valves) | 1440 |
| Radiator Wall To Pipe Centres (mm) | 40 |
| Radiator Colour | Anthracite |
| Model | Aspen Anthracite Horizontal Single |
| Brand | K-Rad Designer Range |
| Fuel Type | Central Heating |
| Width (mm) | 1440 |
| Depth (mm) | 55 |
| Height (mm) | 600 |
| Manufacturer Part No | ASP60-145SA |
Home > Radiators > Designer Radiators > Horizontal Radiators > KRAD Aspen 600 x 1440mm Textured Grey Single
Open-plan kitchen-diners, large bedrooms and bay-windowed reception rooms often need generous width coverage without aggressive heat output — and that is exactly where the
4,227 BTU at Delta T60
1239W
5 Year Guarantee
Textured Grey Matt
Single Panel
600 x 1440mm
SKU: ASP60-145SA
Open-plan kitchen-diners, large bedrooms and bay-windowed reception rooms often need generous width coverage without aggressive heat output — and that is exactly where the Kartell K-Rad Aspen 600 x 1440mm Textured Grey Single Horizontal Radiator earns its place. The 1440mm single panel delivers 4,227 BTU (1,239W) across a wide wall span, providing even background warmth without overheating well-insulated modern rooms. At just 55mm deep it sits closer to the wall than a double, reducing visual weight on already generous wall runs. SKU: ASP60-145SA.
At 1440mm wide and 4,227 BTU, this radiator heats a broad wall area evenly — ideal for well-insulated modern homes or rooms supplemented by underfloor heating where a double panel would create uncomfortable spikes in temperature.
The 55mm single panel depth is 24mm shallower than the double panel equivalent, making it the better choice where kitchen units, sofas or fitted furniture run close to the radiator wall.
A 1440mm radiator in textured grey creates a long, deliberate horizontal feature — a far more considered look than multiple smaller white radiators scattered around the same room.
In rooms with wet underfloor heating providing the base load, this single panel radiator provides the quick-response top-up heat that UFH systems cannot deliver rapidly.
Designed to sit beneath standard window sill heights in compliance with UK building regulations, allowing glazing to reach near to floor level without blocking it.
The full 5 year manufacturer guarantee applies equally to single panel models — this is not a compromise product, it is a deliberate sizing choice.
| Specification | Detail |
|---|---|
| Product Name | Kartell K-Rad Aspen 600 x 1440mm Textured Grey Single Horizontal Designer Radiator |
| SKU / Kartell Code | ASP60-145SA |
| EAN / GTIN-13 | 5055681428723 |
| Height | 600mm |
| Width | 1440mm |
| Depth | 55mm (single panel) |
| Weight | 17.28kg |
| Orientation | Horizontal |
| Colour / Finish | Textured Grey (Matt Powder Coat) |
| Material | Mild Steel |
| Panel Type | Single Panel — Designer Oval Tube |
| BTU Output (Delta T60) | 4,227 BTU |
| Watt Output (Delta T60) | 1239W |
| Fuel Type | Central heating — gas, oil, or compatible electric |
| Pipe Centres | 1440mm |
| Wall to Pipe Centres | 60mm |
| Valve Connection | 1/2 inch BSP |
| Max Working Pressure | 7.8 bar |
| Fixings Supplied | Yes — all wall fixings included |
| Manufacturer Guarantee | 5 years — Kartell UK |
| Valves Included | Not included — sold separately (see Valves tab) |
All outputs quoted at Delta T60 — the European standard assuming 80°C flow / 60°C return in a 20°C room.
Watch our step-by-step guide. All central heating connections must be made by a qualified heating engineer.
| Pipe Centres | 1440mm |
| Wall to Pipe Centres | 60mm |
| Wall Projection | 55mm |
| Valve Connection | 1/2 inch BSP — angled, straight or corner at either end |
| Max Working Pressure | 7.8 bar |
| Compatible Systems | Sealed and open vented — gas, oil, electric |
| Fixings Supplied | Yes — wall brackets, screws, plugs, air vent, blanking plug |
Valves are not included and must be purchased separately. We recommend matching Kartell K-Design Textured Grey TRV twin packs to complement this radiator perfectly. Select your pipework type below.
When to use: Pipework rises vertically from the floor at either end and connects to the bottom tappings. This is the most common UK installation for horizontal radiators.
When to use: Pipework comes straight up through the floor directly into the bottom tapping at either end of the radiator.
When to use: Pipework comes horizontally out of the wall at either end and connects to the side tappings of the radiator valves.
ⓘ Unsure which type? Call 01282 429061 Monday to Friday and our team will advise.
The SA (Single) has a 55mm depth and outputs 4,227 BTU. The DA (Double) is 79mm deep and outputs 7,861 BTU. Both share identical 1440mm pipe centres and external dimensions — only the depth and BTU differ.
For a large UK master bedroom of around 18–25m² with good insulation and double glazing, 4,227 BTU is generally sufficient. For rooms with high ceilings or poor insulation, consider the double panel. Use the BTU Calculator to confirm.
The ASP60-145SA weighs 17.28kg — significantly lighter than the 32.64kg double panel, making wall fixing more straightforward. Standard solid wall fixings are appropriate.
Yes — this is a common and effective combination. The UFH provides steady background warmth and the radiator provides faster response when temperatures need a quick boost, particularly on cold mornings.
Pipe centres are 1440mm. Wall to pipe centres is 60mm. Valves fit at either end of the radiator in the standard horizontal configuration.
The textured grey matt finish is one of the most popular choices for open-plan kitchen-diner spaces precisely because it coordinates with dark cabinetry, stainless steel appliances and polished concrete or slate flooring without competing for attention.
Need a wide but slim textured grey horizontal radiator? The Kartell K-Rad Aspen 600 x 1440mm Textured Grey Single Horizontal Radiator (ASP60-145SA) spans 1440mm in a slim 55mm single panel, outputting 4,227 BTU — ideal for well-insulated open-plan rooms or spaces with supplementary underfloor heating. Search terms: ASP60-145SA, 1440mm textured grey single horizontal radiator, Kartell Aspen 1440 textured grey single, 4227 BTU single panel 1440mm, slim wide textured grey radiator, Kartell K-Rad 600 x 1440 single textured grey.
